BRITISH GENERAL IP66 13A WEATHERPROOF OUTDOOR SWITCHED PASSIVE FUSED SPUR

SKU: 12148-BRI

Credit Plans Available. Find out more

Clearpay_TD_Image

Klarna_TD_Image

V12_TD_Image

Description

WHAT'S IN THE BOX 1x BRITISH GENERAL IP66 13A WEATHERPROOF OUTDOOR SWITCHED PASSIVE FUSED SPUR (20523) NOTES FROM MT EXPERT Angled In-Line Terminals with Backed-Out Captive Screws OVERVIEW BRITISH GENERAL IP66 13A WEATHERPROOF OUTDOOR SWITCHED PASSIVE FUSED SPUR (20523) 13A....

See Full Description

stars-5

5.0 (120 Reviews)

£28.59

£30.00

inc VAT

Qty:

In stock

Order within [hour], for earliest possible delivery on [date_start]

You might also like

Description

WHAT'S IN THE BOX

1x BRITISH GENERAL IP66 13A WEATHERPROOF OUTDOOR SWITCHED PASSIVE FUSED SPUR (20523)

NOTES FROM MT EXPERT

Angled In-Line Terminals with Backed-Out Captive Screws

BRITISH GENERAL IP66 13A WEATHERPROOF OUTDOOR SWITCHED PASSIVE FUSED SPUR (20523)

13A. Switched fused connection unit. RCD protection against the risk of electric shocks. Multiple cable entries and high impact resistance.

IK06 Impact Resistance
Plastic Construction
Angled In-Line Terminals with Backed-Out Captive Screws
Side & Base Knockouts
High Protection from Water & Dust
Power Returns Automatically After Break in Supply
30mA Trip Current
40 Nanosecond Trip Speed Operation
IP66

Active or Passive	Passive
Amp Rating	13 A
Brand	British General
Colour	Grey
Construction Material (Electrical)	Plastic
Fixings Supplied	Fixings & Fittings Not Supplied
IK Rating	IK06
IP Rating	IP66
Indicator Type	Without Indicator
Knockout Position	Side & Base Knockouts
Knockout Size	20 mm
Manufacturer Guarantee	1 Year Guarantee
Max. Electrical Load	3120 W
Model No	WP55RCD-XD
No. of Earth Terminals	2
No. of Knockouts	7
Number of Gangs	1 Gang
Number of Poles	Single Pole
Pack Size	1
Parent Colour	Grey
Pieces in Pack/Case	1
Power Voltage Supply	240 V
Product Depth	90 mm
Product Type	FCU
Switched/Unswitched	Switched
Temperature Range	-20°C to 40 °C
Terminal Capacity	Terminals accept 3 x 2.5mm², 2 x 4mm² or 1 x 6mm² cables
Terminal Description	Angled In-Line Terminals with Backed-Out Captive Screws
With Flex Outlet	Flex Outlet
With RCD	RCD
