CRABTREE STARBREAKER DP TYPE 2 MINIATURE SURGE PROTECTION DEVICE 40KA (174VF)
18th Edition Amendment 2. For use with Crabtree Starbreaker consumer units. Provides protection against overvoltage originating from switching and secondary effects from lightning strikes, protecting the electrical installation and all connected equipment. Status indication and volt-free contact for remote monitoring.
| SPECIFICATION |
| Brand |
Crabtree |
| CSU Device |
SPDs |
| Incomer Fitting Type |
Plug-In |
| Manufacturer Guarantee |
1 Year Guarantee |
| Max. Continuous Voltage (Uc) |
275 V |
| Max. Discharge Current (Imax) |
40 kA |
| Model Name |
Starbreaker |
| Model No |
GB6:SFSBT2SPD3W/1 |
| No. of Phases |
Single-Phase |
| Nominal Discharge Current (In) |
20 kA |
| Number of Poles |
Double Pole |
| Pack Size |
1 |
| Pieces in Pack/Case |
1 |
| Product Type |
Miniature Surge Protection Device |
| SPD Type |
Type 2 |
| Suitable Cable Size |
50 mm² |
