| Advisory Notice |
Electronic dimmable transformer required for Low Voltage Halogen bulbs to take the voltage down from 230V to 12V. |
| Brand |
Knightsbridge |
| Dimmer Switch Operation |
Rotary |
| Fixings Supplied |
Fixings Supplied |
| Indicator Type |
Without Indicator |
| Insert Colour |
Without Inserts |
| Manufacturer Guarantee |
2 Year Manufacturer's Guarantee (T&Cs Apply) |
| Max. Dimmable Load (Fluorescent) |
Not Compatible |
| Max. Dimmable Load (Halogen) |
150 W |
| Max. Dimmable Load (Incandescent) |
200 W |
| Max. Dimmable Load LED) |
150 W |
| Min. Back Box Depth Required |
25 mm |
| Min. Dimmable Load (Fluorescent) |
Not Compatible |
| Min. Dimmable Load (Halogen) |
10 W |
| Min. Dimmable Load (Incandescent) |
10 W |
| Min. Dimmable Load (LED) |
5 W |
| Model No |
SF2193MW |
| No. of Earth Terminals |
1 |
| No. of Ways |
2 Way |
| Number of Gangs |
3 Gang |
| On/Off Switch Operation |
Push |
| Overload Protection |
Current & Thermal Overload Protection |
| Pack Size |
1 |
| Pieces in Pack/Case |
1 |
| Power Voltage Supply |
230 V |
| Product Type |
Intelligent Dimmer Switch |
| Screwed/Screwless |
Screwless |
| Smart Compatibility |
Not Smart |
| Suitable for Dimming LEDs |
LED |
| Switch Operation |
Dimmer |
| Switch Operation Colour |
Colour-Matched |
| Switch Product Type |
Light |
| Switches & Sockets Finish |
Matt |
| Switches & Sockets Product Type |
Dimmer Switch |
| Switches & Sockets Profile Type |
Flat |
| Terminal Capacity |
Terminals accept up to 3 x 1.5mm² cables |
| Terminal Description |
Captive Terminal Screws |
| Waveform |
Leading Edge or Trailing Edge Option |
