KNIPEX 70 06 160 INSULATED VDE DIAGONAL CUTTERS 160MM
Long appreciated by many craftsmen – the insulated KNIPEX 70 06 160 diagonal cutters with a length of 160 mm are a classic in the Knipex range. From the shape of the head through to the polish and hardness of the cutting edges, it is customised for the diverse cutting tasks in the day-to-day work of electricians, mechatronics engineers and electronics engineers.
The Knipex 70 06 160 diagonal cutters are insulated using multi-component grips in accordance with the insulation standard IEC 60900 / DIN EN 60900.
With their cutting capacities of up to Ø 2.0 mm on hard wire (e.g. wire rope fibre) and up to Ø 4.0 mm on soft wire (e.g. copper wire), the Knipex 70 06 160 diagonal cutters offer a broad range of applications.
The long cutting edges make them ideal for cutting cable. The extremely carefully and precisely machined cutting edges enable even very fine stranded wire to be cut accurately – up to the tips of the cutting edges. This is a great advantage where space is restricted, for example when shortening fine stranded wires in junction boxes and distribution boxes.
FEATURES
- With elongated cutting edge
- The indispensable diagonal cutter for all-round use
- High-quality material and precise workmanship for long service life
- Precision cutting edges for soft and hard wire
- Clean cutting of thin copper wires, also at the cutting edge tips
- Cutting edges additionally induction-hardened, cutting edge hardness approx. 62 HRC
- Narrow head style for use in confined areas
- VDE-tested safety up to 1000 volts
- With bevel
- Vanadium electric steel, forged, multi stage oil-hardened
SPECIFICATION
- Article Number: 70 06 160
- EAN: 4003773021995
- Pliers: Chrome-plated
- Head: Chrome-plated
- Handles: Insulated with multi-component grips, VDE-tested
- Weight: 216 g
- Dimensions: 160 x 55 x 20 mm
- Standard: DIN ISO 5749 DIN EN 60900 IEC 60900
- REACH Compliant: Does not contain SVHC
- RoHS Compliant: Not applicable
- Cutting Capacities: Medium Hard Wire (diameter): Ø 4.0 mm / Hard Wire (diameter): Ø 3.0 mm / Piano wire (diameter): Ø 2.0 mm
- VDE Tested: Yes
