LEWDEN PRO 13-MODULE 9-WAY PART-POPULATED MAIN SWITCH CONSUMER UNIT WITH SPD (989HM)
Consumer unit with 100A main switch and Type 2 surge protection kit. Designed for use with Lewden 6kA single module RCBOs, MCBs and AFDD RCBOs. Provides extra wiring space and a selection of round knockouts for versatile and convenient installation. Equipped with 1 x neutral bar. DIN rail mounted.
- 20kA Type 2 SPD
- 1 x Type B MCB (50A)
- 100A Mains Switch
- Floating Busbar
- DIN Rail Supplied
- Top, Bottom & Rear Cable Entry Points
| SPECIFICATION |
| Brand |
Lewden |
| Busbar Type |
Floating Busbar |
| CSU Populated/Unpopulated |
Part-Populated |
| Cable Entry Points |
Top, Bottom & Rear |
| Construction Material (Electrical) |
Steel |
| Consumer Unit Type |
Main Switch |
| Current Rating |
100 A |
| DIN Rail Supplied |
DIN Rail Supplied |
| Fixings Supplied |
Fixings Not Supplied |
| IP Rating |
IP2XC |
| Integrity |
Non High Integrity |
| MCBs Supplied |
MCB |
| Mains Switch Rating |
100A Mains Switch |
| Manufacturer Guarantee |
1 Year Guarantee |
| Model Name |
PRO |
| Model No |
PRO-R12MS |
| No. of Available Ways |
9 |
| No. of MCBs Supplied |
1 x Type B MCB (50A) |
| No. of RCBOs Supplied |
0 x RCBOs |
| No. of RCDs Supplied |
0 x RCDs |
| No. of SPDs Supplied |
20kA Type 2 SPD |
| Pack Size |
1 |
| Pieces in Pack/Case |
1 |
| Power Voltage Supply |
230 V |
| Product Depth |
109 mm |
| Product Height |
268 mm |
| Product Type |
Mains Switch Consumer Unit |
| Product Width |
281 mm |
| RCBOs Supplied |
No RCBOs Supplied |
| RCD Type |
No RCD |
| RCDs Supplied |
No RCDs Supplied |
| SPDs Supplied |
SPD |
| Total No. Module Spaces When Empty |
13 |
| Total Product Weight |
3.19 kg |
| Way |
9 Way |
