New grip design combines the best features from both top handle and barrel grip jigsaw design.
On board fuel gauge and LED light.
REDLITHIUM-ION™ battery pack provides superior pack construction, electronics and fade-free performance to deliver more run time and more work over pack life.
Flexible battery system: works with all Milwaukee® M12™ batteries.
Non marking shoe comes as standard to protect work surfaces from scratching.
REDLINK™ overload protection electronics in tool and battery pack deliver best in class system durability.
Variable speed - electronic trigger provides user flexibility and control.
Smooth cut - minimal vibration during cutting provides ultra smooth performance.
Precision roller guide increases user control and reduces blade deviation.
Line of sight - the compact tool design improves cut line visibility.
Tool free bevel facility - quick and easy bevel adjustment up to 45°.
QUIK-LOK™ T-Shank blade clamp.
Individual battery cell monitoring optimises tool run time and ensures long term pack durability.
Barcode: 4002395242085
Part number: M12 JS-0
Voltage : 12 volt
Bevel capacity : 45°
Max. cutting capacity (aluminium) : 15 mm
Max. cutting capacity (wood) : 40 mm
No load stroke rate : 0 - 2,800 spm
Sound power level : 88.5 dB(A)
Sound power level uncertainty : 3 dB(A)
Sound pressure level : 77.5 dB(A)
Sound pressure level uncertainty : 3 dB(A)
Stroke length : 19 mm
Vibration cutting (metal) : 7.8 m/s²
Vibration cutting uncertainty (metal) : 1.5 m/s²
Vibration cutting (wood) : 10.1 m/s²
Vibration cutting uncertainty (wood) : 1.5 m/s²
**images for illustrative purposes only – please refer to description and specification for full details of product**
