| AC/DC Voltage & Charging |
230V AC Charging |
| Brand |
Project EV |
| Cable Entry Points |
Bottom Only |
| Charging Mode |
Mode 3 |
| Colour |
Black |
| Communication Protocol |
OCPP |
| Compatible with Solar Panels |
Compatible with Solar Panels |
| Construction Material (Electrical) |
Metal |
| Current Rating |
32 A per socket A |
| Display Type |
LCD Display |
| Domestic/Commercial Use |
Suitable for Domestic & Commercial Use |
| EV Plug Type |
Type 2 |
| EV Product Type |
Stations |
| Fitting Requirements |
Must be Fitted by a Qualified and Registered Installer |
| Frequency Band (Smart) |
2.4 GHz |
| Hertz (Hz) |
50 / 60 Hz |
| IK Rating |
IK10 |
| IP Rating |
IP65 |
| Manufacturer Guarantee |
1 Year Guarantee |
| Model Name |
Pro Earth RFID |
| Model No |
PEVEVA07DSEW |
| Mount Type |
Wall-Mountable |
| Network Standards |
802.11b/g/n |
| No. of Phases |
Single-Phase |
| No. of Ports |
2 Port |
| Pack Size |
1 |
| Parent Colour |
Black |
| Pieces in Pack/Case |
1 |
| Plug Type |
Type 2 Socket |
| Power Rating (Watts Kw) |
7.3 kW |
| Power Type |
Mains-Powered |
| Product Depth |
176 mm |
| Product Height |
562 mm |
| Product Type |
Electric Vehicle Charger |
| Product Width |
360 mm |
| RFID Card Included |
RFID Card Supplied |
| Resistant Type |
Weather-Resistant |
| Smart Hub Requirement |
Internet Connection Required |
| Standby Power Consumption |
8 W |
| Switched/Unswitched |
Unswitched |
| Temperature Range |
-25 to 50 °C |
| Total Product Weight |
16 kg |
| Wireless Range (Max.) |
30m |
| Wireless Range Restrictions |
Electronic interference from appliances or physical obstruction, such as brick walls, metal frames and floors, can reduce the wireless range. A signal weakens every time it encounters an obstruction. |
| Works with Amazon Alexa |
Does Not Work with Amazon Alexa |
| Works with Android App |
Works with Android App |
| Works with Apple HomeKit |
Does Not Work with Apple HomeKit |
| Works with Google Home |
Does Not Work with Google Home |
| Works with iOS App |
Works with iOS App |
