WYLEX DP TYPE 2 MINIATURE SURGE PROTECTION DEVICE 40KA (618VF)
18th Edition Amendment 2. For use with Wylex consumer units. Single module including all connections, fits in way 1 next to main switch. Features status indicators showing if the device has been activated and includes volt-free contacts for remote monitoring and signalling. Connects directly to busbar.
| SPECIFICATION |
| Brand |
Wylex |
| CSU Device |
SPDs |
| Incomer Fitting Type |
DIN Rail Mounted |
| Manufacturer Guarantee |
1 Year Guarantee |
| Max. Continuous Voltage (Uc) |
275 V |
| Max. Discharge Current (Imax) |
40 kA |
| Model No |
GB6:SFNMT2SPD3W/1 |
| No. of Phases |
Single-Phase |
| Nominal Discharge Current (In) |
20 kA |
| Number of Poles |
Double Pole |
| Pack Size |
1 |
| Pieces in Pack/Case |
1 |
| Product Type |
Miniature Surge Protection Device |
| SPD Type |
Type 2 |
| Suitable Cable Size |
50 mm² |
